Analog signal Input range

0mV ~ ±20mV

Non-linearity

0.01% F.S. max.

Max. display resolution

1/20,000

Min. input sensitivity

0.5uV/Digit

Temperature Drift

Zero : ±0.1uV/°C RTI max.

SPAN : 10ppm/°C max.

Load Cell Excitation

DC 5V , 60mA

(350 ohm x 4 load cell)

Input noise

±0.3uVpp

Input impedance

10M?

A/D converter

24bit sigma-delta

A/D internal resolusion

1/200,000

A/D Sampling speed

50 times/sec

Display

7 segments LED (14.1mm), 5 digit

Display speed

50times/sec ~ 1times/sec

Polarity indication (-)

"-" Minus sign

Annunciators

Zero, Stable, Relay Point(LO,OK,HI) Hold

Display increments

1,2,5,10,20,50,100,200 selectable

Decimal points

Selectable to any points

Operating Voltage

AC 110，220V±10%，50/60HZ

Power Consumption

Approx. 10VA

Operating Temperature

-10°C ~ 50°C

Output

Standard

Relay 3CH output

Options

1)     RS-232C (Serial output)

2)  RS-422 (Serial output)

3)  RS-485 (Serial output)

4)  DC 0 ~ 10V (Analog output)

5)  DC 4~ 20mA (Analog output)

6)  BCD (Parallel output)

Weight

Approx. 530g
