Analog signal Input range

-34mV ~ +34mV

Non-linearity

0.01% F.S. max.

Max. display resolution

1/20,000

Min. input sensitivity

0.2 u/Digit (min.)

Temperature Drift

Zero : ±0.1 u/°C RTI max.

SPAN : 10ppm/°C max.

Load Cell Excitation

DC 5V, 60mA (350 ohm x 4 load cells)

Input noise

±0.3 upp or less

Input impedance

10M ? or more

A/D converter

24 bits

A/D Sampling speed

2,000 times/sec

Display

Measurement

LED, 7 segments 14.1mm high 6 digit

High/Low

LED, 7 segments 8.0mm high 5 digit

Maximum Display

(-) 19999 ~ (+) 19999 (min. division: 1)

(-) 199950 ~ (+)999950 (min. division: 50)

Display speed

1,000times/sec ~ 1times/sec

Polarity indication (-)

" " Minus sign

Annunciators

LO, OK, HI, HOLD, ZERO

Display increments

1,2,5,10, 20, 50 selectable

Decimal points

Selectable to any points

Operating Voltage

Selectable to any points
AC 85 ~ 240V, 50/60Hz (Free voltage)

Power Consumption

Approx. 20VA

Operating Temperature

-10°C ~ 50 °C

Output

Standard

Relay 3CH Output

&Serial Output (RS-232C & RS-422/485)

Options

1)   DC 0~±10V Isolated Analog Output

(User-changeable to DC 0~±5V)

2）DC 4~20mA Isolated Analog Output

(User-changeable to DC 0~20mA)

3) BCD Parallel Output

Weight

Approx. 700g
