Analog signal Input range

-1mV ~ +34mV

Non-linearity

0.01% F.S. max.

Max. display resolution

1/20,000

Min. input sensitivity

0.3uV/Digit

Temperature Drift

Zero : ±0.2uV/°C RTI max.

SPAN : 20ppm/°C max.

Load Cell Excitation

DC 10V , 300mA

(350 ohm x 8 load cell)

Input noise

±0.3uVpp

Input impedance

10M?

A/D converter

24bit sigma-delta

A/D internal resolusion

1/200,000

A/D Sampling speed

50 times/sec

Display

VFD, 7 segments green, 13mm high

Display speed

50times/sec ~ 2times/sec

Polarity indication (-)

"-" Minus sign

Annunciators

Stable, Zero, L1, L2, L3, L4, Tare

Display increments

1,2,5,10,20,50,100,200-selectable

Decimal points

Selectable to any points

Operating Voltage

AC 110, 220V ±10%, 50/60Hz

Power Consumption

Approx. 20VA

Operating Temperature

-10°C ~ 40°C

Output

Standard

RS-232C serial output

Options

1)  RS-422/485 (Serial output)

2)   Current loop

3)  DC 0~10V (Voltage output)

4)  DC 4~20mA (Current output)

5)  BCD Parallel output

Weight

Approx. 2.5kg
