PARAMETER

參數

VALUE

Rated capacity-R.C. (Emax)

量程

1500，2000，3000，5000Kg

NTEP/OIML Accuracy class

精度

E

G

Maximum no,of intervals(n)

分度值

1000

3000

Rated output-R.O.

額定輸出

2.0 mv/v±0.002%

Zero Balance

零點平衡

±0.2%

Zero return 30 minutes

零點恢復

±0.0500%

±0.0170%

Total Error

總誤差

±0.0500%

±0.0200%

Temp.effect on zero

零點溫漂

±0.0300%

±0.0040%

Temp.effect on output

靈敏度溫漂

±0.0030%

±0.0012%

Temperature range

可用溫度范圍

-10°C to + 40°C

Temperature range, safe

溫度補償范圍

-20°C to + 70°C

Maximum safe central overload

安全載荷

150%

Ultimate overload

極限載荷

300%

Excitation, recommended

推薦激勵電壓

10VDC/AC

Excitation, maximum

最大激勵電壓

15V DC/AC

Input impedance

輸入阻抗

385 ohm±15 ohm

Output impedance

輸出阻抗

350 ohm±3 ohm

Insulation resistance

絕緣阻抗

>2000 M ohm

Cable length

線長

5.0m

Environmental protection

防護等級

IP67
