PARAMETER

參數

VALUE

NTEP/OIML Accuracy class

精度

GW

JW

C3

Rated capacity-R.C. (Emax)

量程

0.3，0.6，1.5，3.0Kg

Rated output-R.O.

額定輸出

0.9 mv/v±0.1%

Zero Balance

零點平衡

±0.045%

Zero return 2 minutes

零點恢復

±0.0100%

±0.0033%

Zero return 30 minutes

±0.0170%

Total Error

總誤差

±0.0040%

±0.0040%

±0.004%

Temp.effect on zero

零點溫漂

±0.0020%

±0.0020%

±0.001%

Temp.effect on output

靈敏度溫漂

±0.0010%

±0.0030%

±0.0010%

Eccentric loading error

偏心加載誤差

±0.0033%

Temperature range

可用溫度范圍

5°C to + 40°C

Temperature range, safe

溫度補償范圍

-3°C to + 70°C

Maximum safe central overload

安全載荷

150%

Ultimate overload

極限載荷

250%

Excitation, recommended

推薦激勵電壓

10VDC/AC

Excitation, maximum

最大激勵電壓

15V DC/AC

Input impedance

輸入阻抗

415 ohm±20 ohm

Output impedance

輸出阻抗

350 ohm±3 ohm

Insulation resistance

絕緣阻抗

>2000 M ohm

Cable length

線長

3.0 m -3410  6.0 m -3411

Environmental protection

防護等級

IP67

Platform size (max)

最大秤臺尺寸

200×200mm
