PARAMETER

參數(shù)

VALUE

Standard capacities(Emax)

量程

6， 12， 30， 60Kg

NTEP/OIML Accuracy class

精度等級

NTEP IIIL

D3

C3(3)

C6(2)

Min. verification interval (Vmin)

分度值

10000

3000

6000

Y=Ema*Vmin

Emax/12000

Rated Output

額定輸出

2 mv/v (1.75 for 0.25T ,2.05 for 10T)

Rated output tolerance

額定輸出容差

±0.0.1%

Zero Balance

零點平衡

±1.0%

Combined error

綜合誤差

±0.0200%

±0.0300%

±0.0230%

±0.0115%

Creep error  30 minutes

蠕變

±0.0245%

±0.0123%

Temp.effect on output

靈敏度溫漂

±0.0010%

±0.0010%

±0.0070%

±0.0045%

Temp.effect on zero

零點溫漂

±0.0008%

±0.0008%

±0.0050%

±0.0025%

Safe Overload

安全載荷

150%

Ultimate overload

極限載荷

300%

Rated Excitation

推薦激勵電壓

5 to 15 VDC/AC

Maximum Excitation

最大激勵電壓

30V DC/AC

Input Impedance

輸入阻抗

1100 ohm±50 ohm  0.25T-10T

1075 ohm±100 ohm  28T

1350 ohm±100 ohm  60T

Output Impedance

輸出阻抗

1025 ohm±50 ohm  0.25T-10T

930 ohm±0.5 ohm  28T

1175 ohm±0.5 ohm  60T

Insulation Resistance

絕緣阻抗

>5000 M ohm

Compensated temperature range

溫度補(bǔ)償范圍

-10°C to + 40°C

Operating temperature range

工作溫度范圍

-30°C to + 70°C

Storage temperature range

存儲溫度范圍

-50°C to + 80°C

Environmental proteciom

防護(hù)等級

IP66、IP68
